General purpose use
Suitable for materials up to 1000N/mm2
Through & blind holes
Suitable for both hand and machine operations
Depths up to approx. 1 x d1
Specifications
Designation: N
Material: HSS
Finish: Brt
Max Cut Depth: 1xD
Shank Form: A
Standard: ISO529
Thread Form: BSW
Nut Tolerance: Z3 Medium
Lead: Set
TPI: 12
Limit: Z3
Length l1 (mm): 95
Length l2 (mm): 30
Diameter d2 (mm): 11.2
sq: 9
Length l4 (mm): 12
z: 4
