General-purpose use
Suitable for materials up to 1000N/mm2
Suitable for both hand and machine operations
Depths up to approx. 1 x d1
Specifications
Designation: N
Finish: Brt
Shank Form: A
Type: Straight Flute
Thread Form: M
Lead: Taper
Material: HSS
Max Cut Depth: 1xD
x: als
Standard: ISO529
Nut Tolerance: ISO 2 / 6H
Size:
d1: M8
11: 72
l2: 22
d2: 8
sq: 6.3/li>
l4: 9
z: 4
Drill Ø: 6.8
Pitch: 1.25
